Description
The AM Receiver Kit by Zodiac Overseas is an essential training system designed to study the reception and demodulation of amplitude modulated signals. Engineered for educational use, this kit allows students to explore real-time AM signal detection and audio retrieval with clarity and precision.
Key Features:
- Complete setup for receiving and demodulating AM signals
- Built-in tuned RF amplifier and detector circuit
- High-sensitivity demodulation using diode detector
- Integrated audio amplifier for clear output
- Output terminals for connecting external speaker or CRO
- Test points provided for detailed circuit study
- Compact and durable design with clear labeling of components
- Supplied with a comprehensive manual and lab experiments
Educational Applications:
- Demonstrates the process of AM signal reception and demodulation
- Ideal for communication labs in engineering, diploma, and polytechnic courses
- Enables practical understanding of superheterodyne principles (in advanced variants)
Power Supply: Operates on 230V ±10%, 50Hz AC (or as per requirement)
Scope of Supply:
- AM Receiver Trainer Unit
- Output Speaker or Headphone (optional)
- Patch Cords
- Instruction Manual
Perfectly complements our AM Transmitter Kit for a complete analog communication lab setup.
