Description
Key Features:
- Voltage Multiplication: The circuit increases the input voltage to approximately three times its peak value. For instance, with an input of 100 V peak, the output would be around 300 V DC, minus diode voltage drops. Basic Electronics Tutorials
- Component Configuration: It typically consists of a combination of diodes and capacitors arranged in a specific sequence. The capacitors charge during different phases of the AC cycle, and the diodes direct the current flow, resulting in cumulative voltage addition.
- Applications: Voltage tripler circuits are used in applications requiring high DC voltages from lower AC sources, such as in CRT displays, photocopiers, and certain types of power supplies.
